Precision, temperature control, and intelligent automation—unified in one advanced simulation platform.
◆ Accuracy That Anchors Every Measurement
±5 arc-second positioning accuracy across all three axes ensures your test data reflects true device performance. Triaxial rotation axis perpendicularity maintained within 10 arc-seconds—because alignment precision underpins every measurement.
◆ Speed That Spans the Spectrum
Inner frame reaches 400°/s, middle frame 300°/s, outer frame 200°/s, with three-axis coordinated motion at 100°/s. Rate stability scales intelligently: 5e-003 over 1° average, 5e-004 over 10° average, and 5e-005 over 360° average—delivering clean, artifact-free motion at every speed.
◆ Acceleration That Mirrors Real-World Dynamics
Inner frame delivers 300°/s², middle frame 200°/s², outer frame 100°/s²—enough to simulate rapid attitude corrections, target acquisition maneuvers, and stabilization disturbances without exceeding payload limits.
◆ Boundless Rotation for Comprehensive Testing
360° continuous rotation on every axis eliminates mechanical constraints, enabling uninterrupted multi-turn profiling and extended endurance runs without range limitations.
◆ AI-Intelligent Control for Smarter Testing
Advanced AI control technology delivers high-precision, low-noise operation with consistent performance across long-term use. The system adapts to complex test profiles, reducing manual intervention and accelerating test campaigns.
◆ Precision Mechanical Foundation
Φ300 mm × 300 mm load capacity table maintains 0.02 mm flatness and 0.03 mm end runout, providing a stable, repeatable mounting surface for sensitive test articles.
◆ Reliable Signal Transmission
Conductive slip ring with 30+ channels—8 power rings at 3A and 22 signal rings at 2A—ensures clean power and data transfer throughout continuous rotation. Data transmission frequency reaches ≥100 Hz for real-time monitoring and control.
◆ Integrated Thermal Chamber for Environmental Realism
Customizable test chamber spans -55°C to +80°C with ±0.5°C fluctuation, ±2.0°C deviation, and 2.0°C uniformity. Cooling and heating rates reach 3°C/min across the entire range with representative 20 kg thermal loads—enabling efficient thermal cycling without compromising test throughput.
◆ Applications
Inertial navigation system validation. Gyroscope and accelerometer characterization. Aerospace sensor testing. Precision instrument calibration. Research and development.
◆ The Intelligent Choice for Environmental Motion Testing
By unifying AI-driven precision, wide-ranging thermal control, and robust multi-axis performance, this simulation system delivers the capabilities engineers need for advanced sensor development. For professionals who demand accuracy, intelligence, and environmental fidelity in one integrated platform, it provides the confidence to push testing boundaries—further and faster.
