Precision motion simulation doesn't have to be complicated. This single-axis rate table delivers high performance in a straightforward, reliable package.
◆ Accuracy That Sets the Standard
±2 arc-second rotation accuracy backed by ±5 arc-second positioning accuracy and ±3 arc-second repeatability ensures your test data reflects true device behavior—not table error. For inertial component calibration, this level of certainty is non-negotiable.
◆ Speed That Covers the Spectrum
Rates from ±0.001°/s to ±1000°/s accommodate everything from ultra-slow drift characterization to high-speed dynamic sweeps. Rate stability holds at 3×10⁻⁵ over 360° average, delivering clean, artifact-free motion across the entire envelope.
◆ Acceleration That Mirrors Real-World Dynamics
Maximum angular acceleration of 300°/s² under rated load, plus rocking frequency from 0.02 Hz to 10 Hz, enables realistic attitude simulations and vibration testing for dynamic applications.
◆ Precision Construction for Stable Results
φ320 mm table with 0.02 mm flatness and 0.02 mm end runout provides a stable, repeatable mounting surface for sensitive test articles. The high-flatness countertop ensures consistent contact and reliable data across thousands of test cycles.
◆ Generous Payload Capacity
Supporting 20 kg loads, the system accommodates a broad range of inertial components, gyroscopes, accelerometers, and optoelectronic devices without custom fixturing.
◆ Unrestricted Continuous Rotation
360° continuous rotation eliminates mechanical stops, enabling unlimited multi-turn testing and extended endurance runs without range anxiety.
◆ Reliable Signal Transmission
30-ring conductive slip ring ensures uninterrupted power and data transfer throughout continuous rotation—critical for active test articles with onboard electronics.
◆ Flexible Control for Any Environment
Touch screen interface enables intuitive local operation, while RS232/RS422 remote control supports automated test sequences and seamless integration with existing data acquisition systems.
◆ Designed for Efficiency and Longevity
Delivers 30% higher testing accuracy compared to standard rate tables, cuts equipment downtime by 25%, and reduces maintenance costs through durable construction and consistent performance.
◆ Applications
Inertial component calibration. Gyroscope and accelerometer characterization. Motion simulation for sensor validation. Production quality assurance. Research and development.
◆ Precision Simplified
This rate table proves that high accuracy doesn't require complexity. For engineers and technicians who need reliable, repeatable motion simulation in a straightforward package, it delivers the performance you need—day in, day out.
