Built for the lab. Engineered for industry. Trusted for precision.
◆ Accuracy That Anchors Your Data
±20 arc-second positioning accuracy backed by ±5 arc-second repeatability ensures consistent, defensible test results. For dynamic testing and calibration workflows, this level of repeatability translates directly to confidence in your measurements.
◆ Boundless Rotation for Unrestricted Testing
360° continuous rotation on every axis eliminates mechanical stops, enabling comprehensive attitude profiling and extended endurance runs without range limitations.
◆ Speed That Spans the Spectrum
Inner frame reaches 500°/s, middle frame 400°/s, outer frame 300°/s, with three-axis coordinated motion at 100°/s. Rate stability holds at 2×10⁻⁴ over 360° average, 2×10⁻³ over 10° average, and 2×10⁻² over 1° average—delivering clean, artifact-free motion.
◆ Acceleration That Mirrors Real-World Dynamics
Inner frame delivers 300°/s², middle frame 200°/s², outer frame 100°/s²—enough to simulate rapid attitude corrections, target acquisition maneuvers, and stabilization disturbances without exceeding payload limits.
◆ Precision Construction for Stable Results
Φ320 mm super-hard aluminum alloy table maintains 0.03 mm flatness and 0.03 mm end runout. M8 threaded inserts with 25 mm spacing (4-turn, 8-ray distribution) provide flexible fixture mounting. Triaxial rotation axis perpendicularity within ±15″, intersection within Φ0.5 mm sphere.
◆ Generous Payload in a Compact Package
Supporting 15 kg loads with Φ280 mm × 150 mm maximum dimensions, the system accommodates a broad range of inertial components, sensors, and optoelectronic devices. At approximately 60 kg, it offers laboratory-grade performance in a footprint suited for space-constrained facilities.
◆ Reliable Signal Transmission
30-ring slip ring assembly features 14 single-core shielded channels at 3A and 16 double-core shielded channels at 2A—ensuring uninterrupted power and data transfer throughout continuous rotation.
◆ Engineered for Efficiency
Delivers up to 40% higher repeatability compared to standard tables, reducing calibration cycle time by 30% while maintaining superior stability across demanding dynamic testing applications.
◆ Applications
Laboratory motion simulation. Inertial component calibration. Gyroscope and accelerometer characterization. Industrial testing and quality assurance. Research and development.
◆ The Smart Choice for Precision Motion
This triaxial rate table is more than equipment—it is a dependable partner for engineers and technicians who demand repeatability, stability, and efficiency. By delivering consistent performance across demanding test scenarios, it helps you focus on what matters: validating your technology with confidence.
