High accuracy. High dynamics. High confidence.
◆ Accuracy That Defines Excellence
±5 arc-second positioning accuracy with ±3 arc-second repeatability ensures your test data captures true device performance. For inertial measurement unit verification, this level of precision is non-negotiable.
◆ Unrestricted Rotation for Continuous Testing
Continuous unlimited angular travel removes mechanical barriers, enabling uninterrupted multi-turn testing without range anxiety—ideal for comprehensive performance characterization.
◆ Exceptional Dynamic Performance
Maximum angular acceleration reaches 5000°/s² with 220 Hz bandwidth, enabling rapid attitude transitions and high-frequency dynamic excitation. Waveform distortion maintained within 5% for clean, artifact-free motion profiles.
◆ Rate Stability That Inspires Confidence
Rate accuracy and smoothness hold at 5×10⁻⁵ over 360° average—delivering consistent, reliable motion across the entire speed envelope for demanding calibration sequences.
◆ Precision Construction for Stable Results
φ500 mm aluminum alloy table with 0.03 mm flatness and 0.05 mm end runout provides a stable, repeatable mounting surface for sensitive test articles.
◆ Generous Payload Capacity
Supporting 10 kg loads, the system accommodates a broad range of inertial measurement units, gyroscopes, accelerometers, and navigation components.
◆ Integrated Control for Automated Testing
Combines position, rate, and swing control functions in one platform. Speed display and overspeed protection ensure safe, reliable operation. Stable structure and easy operation minimize setup time and accelerate test campaigns.
◆ Applications
Automated IMU testing. Inertial sensor calibration. Gyroscope and accelerometer characterization. Dynamic excitation testing. Industrial sensor performance verification. Navigation unit validation.
◆ Precision That Powers Performance
This turntable is purpose-built for engineers who need high-accuracy angular positioning and dynamic excitation in a reliable, easy-to-operate package. By delivering consistent, repeatable results across demanding test scenarios, it helps you validate your technology with confidence—from development through production.
