This turntable doesn't just rotate—it calibrates, simulates, and validates with the consistency that inertial sensor testing demands.
◆ Precision That Carries Through
±5 arc-seconds positioning. ±2 arc-seconds repeatability. 0.36 arc-seconds resolution. Not one-time accuracy—performance that holds across every test sequence, every device, every shift.
◆ Speed That Covers Your Envelope
Main axis from 0.001°/s to 500°/s. Pitch from 0.001°/s to 300°/s. Resolution at 0.0001°/s. Rate smoothness holds tight: 3e-003 over 1°, 3e-004 over 10°, 3e-005 over 360°. Clean data at every speed.
◆ Two Ways to Test: Rotation and Swing
Continuous 360° rotation for unlimited multi-turn profiling. Swing mode—main axis ±30° at 0.02–10 Hz, pitch ±20° at 0.02–5 Hz—for dynamic response and vibration characterization. One platform, broader capability.
◆ Acceleration That Simulates Real Motion
300°/s² maximum. Paired with 60°/s biaxial linkage speed, this turntable replicates the transient dynamics that inertial sensors encounter in actual operation.
◆ A Foundation That Stays Flat
580 mm stainless steel tabletop. 0.02 mm flatness. 0.03 mm end runout. Axis perpendicularity within ±5″. Your devices mount on a surface that doesn't compromise your measurements.
◆ Payload That Handles Real Hardware
40 kg capacity. Gyroscopes, accelerometers, complete IMU assemblies—the equipment you actually test, not just lightweight samples.
◆ Where This Turntable Excels
Inertial sensor calibration. Gyroscope and accelerometer characterization. IMU performance validation. Dynamic motion simulation. Production test and quality assurance.
◆ The Takeaway
This is a rate turntable that understands its job—delivering accurate, repeatable motion so you can validate sensor performance with confidence, whether you're in R&D or production.
