Some test tables carry weight. Others deliver accuracy. This one does both—without compromise.
◆ Precision That Handles the Load
±30 arc-seconds positioning accuracy. ±5 arc-seconds repeatability. Both axes. Whether you're rotating continuously through 360° or pitching across -180° to +180°, the numbers hold—even under 400 kg of payload.
◆ Rotation That Never Stops
Self-rotation axis: 360° continuous. No stops, no resets, no range anxiety. Multi-turn testing and extended profiling run as long as your test requires.
◆ Pitch That Covers the Arc
-180° to +180°. Full hemispherical coverage for attitude simulation, sensor characterization, and navigation system validation.
◆ Lock It Where You Need It
Fine-tuning capability on both axes. Lock securely at any position within the movement range. Locking angular displacement held to 10″—so your setup stays put when you need it to.
◆ Dual-Mode Operation
Manual adjustment for fine positioning. Electric drive at 0° to 5°/s for automated sequences. One table, two ways to work—choose what fits your workflow.
◆ Built for Real Payloads
≥400 kg capacity. φ600 mm table with 300 mm hollow bore. T-slots for versatile mounting. This isn't a table that struggles with weight—it's designed for the hardware you actually test.
◆ Compact Footprint, Serious Capability
≤1.5 m × 1.0 m platform area. Big performance without dominating your facility.
◆ Where This Table Excels
Inertial navigation system validation. Heavy sensor and component testing. Aerospace and defense equipment qualification. Production and R&D environments where payload capacity meets positioning precision.
◆ The Takeaway
This is a test table that understands what heavy-duty navigation testing actually requires—precision under load, flexibility in operation, and a footprint that fits your facility. It delivers on all three.
