Precision navigation demands precision testing. This triaxial motion simulator delivers both.
◆ Accuracy That Anchors Navigation Performance
±5 arc-second positioning accuracy with ±3 arc-second repeatability across azimuth, pitch, and roll ensures every measurement reflects true sensor behavior. For strapdown navigation systems, where angular errors compound into position drift, this level of fidelity is non-negotiable.
◆ Exceptional Resolution for Fine Characterization
0.0001° angular position resolution paired with 0.0001°/s rate resolution enables ultra-fine control for demanding calibration sequences. This granularity captures subtle sensor responses that coarser systems simply miss.
◆ Speed That Spans the Spectrum
Azimuth reaches 200°/s, pitch 300°/s, roll 400°/s, with minimum speed down to 0.0005°/s for ultra-slow drift characterization. Rate accuracy holds at 5×10⁻³ over 1° average, 5×10⁻⁴ over 10° average, and 5×10⁻⁵ over 360° average—clean motion across the entire envelope.
◆ Acceleration That Mirrors Real-World Dynamics
Azimuth delivers 100°/s², pitch 150°/s², roll 200°/s²—enough to simulate rapid attitude corrections, target acquisition maneuvers, and dynamic disturbances for thorough navigation system evaluation.
◆ Boundless Rotation for Unrestricted Testing
Infinite continuous rotation on all three axes eliminates mechanical stops, enabling uninterrupted multi-turn profiling and extended endurance runs without range limitations.
◆ Precision Alignment You Can Trust
Two-axis perpendicularity maintained within ±3 arc-seconds across all axis pairs. Turning accuracy holds at ±3 arc-seconds for azimuth, pitch, and roll—ensuring uncompromised multi-axis coordination.
◆ Generous Payload and Load Dimensions
Supporting 40 kg loads with dimensions up to 450×440×480 mm, the system accommodates complete strapdown navigation assemblies, IMU units, and large sensor suites without custom fixturing.
◆ Applications
Strapdown navigation system validation. IMU and INS calibration. Gyroscope and accelerometer characterization. Aerospace sensor testing. Research and development.
◆ The Professional-Grade Testing Solution
This triaxial motion simulator is purpose-built for engineers who demand uncompromising accuracy in navigation component testing. By delivering exceptional resolution, wide dynamic range, and reliable repeatability, it provides the confidence to validate performance—from component characterization to system-level integration.
