Optical measurement, laser interferometry and automated equipment R&D demand ultra-precise multi-angle dynamic simulation. This triple-frame precision rotator adopts independent axis control and full-range error compensation to deliver stable high-accuracy motion testing.
◆ Full 360° rotation for all axes with flexible loading space. Inner, middle and outer frames achieve dead-angle-free continuous rotation. The φ200mm cubic loading zone bears up to 10.5kg for small & medium optical assemblies. The ultra-precise tabletop holds minimal magnetic leakage to prevent interference with delicate optical components.
◆ Arc-second multi-dimensional precision cuts test errors. Rotation accuracy and inter-axis verticality stay within ±5″, with repeatability as low as ±4″ and 3.6″ angular resolution. Stable rate accuracy across all speeds and controlled amplitude error faithfully reproduce diverse dynamic motion conditions.
◆ Hierarchical powerful dynamic performance for all test scenarios. The inner frame reaches 450°/s top speed and 1150°/s² acceleration, with graded performance on middle & outer frames. The minimum speed hits 0.01°/s, covering static micro-angle calibration and high-speed dynamic excitation.
◆ Wide industry compatibility & complete custom service. Suitable for optical calibration, laser interferometry, robotics and VR lab research. Equipped with dedicated control cabinet, it supports customized control software and factory lifetime on-site service for lab and automatic production line integration.
