High-Accuracy Single-Axis Position Rate Turntable with 500mm Platform & 30-Ring Slip Ring for Static & Dynamic Calibration of Civil Inertial Navigation Units

Civil inertial navigation and industrial sensor R&D require both static positioning and high-speed dynamic rate testing. This integrated single-axis turntable adopts precision machining and intelligent servo control to deliver stable long-term calibration solutions. ◆ Large flat stainless steel platform for stable fixture mounting. The 500mm tabletop holds tight flatness and runout tolerance, supporting 40kg medium inertial components. Pre-drilled mounting holes and adjustable leveling feet simplify lab setup. ◆ Arc-second ultra-precision with smooth performance across all speeds. It achieves ±2″ rotation accuracy and ±3″ repeatability, with superior rate stability at full speed range. Max 1000°/s speed and 0.02–10Hz swing frequency replicate diverse dynamic motion conditions. ◆ Built-in 30-channel slip ring avoids cable tangling during full rotation. Wires for test units rotate synchronously with the table, eliminating repeated wiring work and enabling long-duration continuous automatic testing. ◆ Dual control modes for lab and production automation. Local touchscreen operation plus RS232/422 remote interface support static positioning, rate rotation and low-frequency swing tests, serving as a cost-effective choice for civilian inertial measurement calibration.
