Precision meets versatility. This two-axis turntable handles the full spectrum of inertial testing—from static calibration to dynamic simulation.
◆ Accuracy That Anchors Your Data
±5 arc-second positioning accuracy, ±2 arc-second repeatability, and 0.36 arc-second resolution ensure every measurement reflects true sensor performance, not table error. For gyroscope and accelerometer characterization, this level of fidelity is non-negotiable.
◆ Speed That Covers the Spectrum
Main axis reaches 500°/s, pitch axis delivers 300°/s, with dual-axis coordinated motion at 60°/s. Velocity resolution down to 0.0001°/s provides fine-grained control for demanding calibration sequences. Rate smoothness scales intelligently: 3e-003 over 1° average, 3e-004 over 10° average, and 3e-005 over 360° average.
◆ Acceleration That Mirrors Real-World Dynamics
Maximum angular acceleration of 300°/s² on the main axis simulates rapid attitude transitions and transient motion processes, enabling realistic dynamic testing without exceeding payload limits.
◆ Dual-Mode Testing: Rotation and Swing
Beyond continuous unlimited rotation, both axes support swing mode—main axis at 0°~±30° with 0.02Hz~10Hz frequency, pitch axis at 0°~±20° with 0.02Hz~5Hz frequency. This adds another dimension of testing for vibration-sensitive sensors and stabilization systems.
◆ Precision Construction for Stable Results
An ultra-flat stainless steel tabletop with 0.02 mm flatness and 0.03 mm end runout, plus rotational axis perpendicularity maintained within ±5 arc-seconds, ensures a stable, repeatable foundation for sensitive test articles.
◆ Generous Payload Capacity
Supporting 40 kg loads on a 580 mm table, the system accommodates complete sensor assemblies, navigation components, and large optoelectronic payloads without disassembly or custom fixturing.
◆ Applications at a Glance
Inertial sensor calibration. Gyroscope and accelerometer characterization. IMU validation. Dynamic motion simulation. Stabilization system testing. Research and development.
◆ A Versatile Partner for Inertial Testing
By unifying high-precision positioning, wide-rate capability, and swing-mode flexibility, this turntable delivers the performance engineers need for both static and dynamic test scenarios. For professionals who demand accuracy, versatility, and repeatability, it provides a dependable foundation for confident sensor validation.
