Real-world performance demands real-world conditions. This test table brings both—precision motion and thermal fidelity—in one integrated platform.
◆ Accuracy That Survives the Extremes
±3 arc-second positioning accuracy, 0.36 arc-second resolution, and <2 arc-second repeatability across all three axes ensure your test data reflects true device performance—whether at -50°C or +70°C. Orthogonality and wobble maintained within ±3 arc-seconds for uncompromised alignment.
◆ Boundless Rotation for Comprehensive Testing
Continuous angular freedom on every axis enables uninterrupted multi-turn profiling, extended endurance runs, and complex attitude sequences without mechanical restrictions.
◆ Speed That Spans the Spectrum
Inner axis reaches 500°/s, middle 200°/s, outer 100°/s, with three-axis coordinated motion at 60°/s. Rate stability scales intelligently: ≤1×10⁻³ over 1° average, ≤1×10⁻⁴ over 10° average, and ≤1×10⁻⁵ over 360° average—clean motion across the entire envelope.
◆ Acceleration That Mirrors Real-World Dynamics
Inner axis delivers 500°/s², middle 150°/s², outer 100°/s² under load—enough to simulate rapid attitude corrections, target acquisition maneuvers, and stabilization disturbances with remarkable fidelity.
◆ Dual-Mode Testing: Rotation and Swing
Beyond continuous rotation, all axes support swing mode at 0.2° amplitude—inner axis up to 10 Hz, middle and outer up to 3 Hz. This adds another dimension of testing for vibration-sensitive sensors and dynamic response characterization.
◆ High-Capacity Signal and Power Transmission
80 signal ways at 3A with 380VAC/50Hz and 40 kW maximum power, plus 6 power ways at 220V/10A—ensuring uninterrupted data and power transfer to active test articles throughout continuous rotation.
◆ Integrated Thermal Chamber for Environmental Realism
600×600×600 mm working volume spans -50°C to +70°C with ±1°C stability, ±1°C deviation, and 2°C gradient. Heating and cooling rates reach 2°C/min, enabling simultaneous thermal cycling and dynamic motion—eliminating the uncertainties of cross-platform transfers.
◆ Built for Heavy-Duty Applications
Supporting 60 kg loads with height up to 500 mm on a Φ550 mm table, the system accommodates complete navigation assemblies, autonomous driving sensor suites, and industrial robotics components.
◆ Applications
Autonomous driving sensor validation. Industrial robotics navigation testing. Inertial navigation system characterization. Environmental adaptability evaluation. Aerospace and defense component testing.
◆ The Complete Environmental Motion Test Platform
By unifying high-precision three-axis positioning, wide-range thermal conditioning, and high-capacity signal transmission, this test table delivers the performance engineers need for comprehensive environmental adaptability validation. For professionals who must qualify systems across temperature extremes and dynamic conditions, it provides the confidence to validate performance—before real-world deployment.
