New Heavy-Duty Vertical 3-Axis Servo Simulation Turntable with Large Mounting Space for High-Precision Dynamic Component Calibration

R&D labs and precision component testing industries demand high load capacity, wide motion range and superior angular accuracy. Our vertical 3-axis servo simulation turntable adopts multi-layer rigid frame to deliver an all-in-one dynamic testing solution with heavy load, wide travel and ultra precision. ◆ Multi-layer vertical frame with oversized hollow mounting area. Designed in vertical layout with double U-shaped outer & middle frames and hollow cylindrical inner frame, it offers over 640mm inner mounting diameter and 1200mm front loading aperture for large test pieces. Three axes move independently, azimuth and pitch cover wide tilt angles, while roll axis provides continuous 360° rotation for full-condition motion simulation. ◆ Rigid heavy-load structure with powerful dynamic performance. The mechanical frame stably supports loads up to 500kg, with 100°/s angular velocity and acceleration. It runs smoothly during high-speed start and stop, supporting long-term continuous testing of heavy components and reproducing diverse high-speed motion states. ◆ High-precision angle control for consistent test data. It achieves outstanding static positioning and arc-second level repeat positioning accuracy. Matched with closed-loop servo real-time feedback, it keeps consistent data across repeated test cycles and cuts calibration errors to meet strict precision inspection standards. ◆ Cross-industry compatible for easy integration. The integrated vertical unit fits research laboratories, optoelectronic R&D, precision sensor tuning and industrial component dynamic simulation. Its modular design connects seamlessly with automatic inspection systems and maintains stable long-term operation.
