Temperature changes. Motion continues. Accuracy remains.
◆ Precision That Withstands Extremes
±3 arc-second positioning accuracy and ±1 arc-second repeatability ensure your test data remains trustworthy—whether at -55°C or +125°C. Two-axis rotation accuracy holds at ±3 arc-seconds, with intersection within φ0.5 mm and perpendicularity within ±3 arc-seconds.
◆ Wide Thermal Range for Comprehensive Testing
The integrated temperature chamber spans -55°C to 125°C with internal dimensions of at least 600×600×500 mm. Temperature deviation and uniformity are maintained within ±2°C, while heating and cooling rates reach 2°C/min across the entire range. This enables simultaneous thermal stress and dynamic motion—eliminating the uncertainties of transferring test articles between separate systems.
◆ Boundless Rotation for Unlimited Testing
Continuous and infinite rotation on both axes eliminates mechanical constraints, enabling uninterrupted multi-turn testing for comprehensive attitude profiling and extended endurance runs.
◆ Speed That Adapts to Your Needs
Inner axis reaches 500°/s, outer axis delivers 360°/s, with acceleration up to 400°/s² on the inner axis and 150°/s² on the outer axis. Speed resolution of 0.0005°/s provides fine-grained control for demanding calibration sequences.
◆ Rate Stability from Crawl to Full Speed
Accuracy and smoothness scale intelligently: ≤2×10⁻³ over 1° average at low speeds, ≤2×10⁻⁴ over 10° average, and ≤2×10⁻⁵ over 360° average at full speed. Clean, artifact-free motion across every operating point.
◆ Generous Payload and Precision Work Surface
Supporting 30 kg loads on a φ500 mm table with 0.02 mm flatness and 0.03 mm runout, the system accommodates diverse device types from compact sensors to larger navigation assemblies and optoelectronic payloads.
◆ Engineered for Long-Term Reliability
Designed for extended test campaigns, the system maintains measurement stability and calibration integrity across thousands of operating hours, reducing recalibration frequency and maintenance overhead.
◆ Applications
Inertial navigation system calibration. Gyroscope and accelerometer characterization. Aerospace sensor validation. Optoelectronic device testing. Production quality assurance. Research and development.
◆ The Complete Environmental Test Platform
By unifying high-accuracy dual-axis positioning, wide-range thermal conditioning, and robust mechanical construction, this turntable eliminates cross-platform handling errors and accelerates development cycles. For engineers who need to qualify sensors across both temperature extremes and dynamic motion, it delivers confidence—in every degree, at every degree.
