Precision sensor validation demands the convergence of high-speed positioning, thermal cycling, and clean signal transmission. This dual-axis turntable delivers all three.
◆ Exceptional Positioning Precision
±3 arc-second accuracy, ±1 arc-second repeatability, and 0.36 arc-second resolution ensure reliable data for optical alignment, antenna mapping, and gimbal characterization.
◆ Ultra-Wide Speed Range
Inner axis reaches 1000°/s, outer axis 600°/s, with accelerations of 400°/s² and 100°/s² under load. From 0.001°/s drift tests to high-speed dynamic simulations, one platform covers all.
◆ Superior Rate Stability
Rate stability holds at 1×10⁻³ (1° average), 1×10⁻⁴ (10° average), and 1×10⁻⁵ (360° average), eliminating motion-induced artifacts across all speeds.
◆ High-Integrity Signal Transmission
140-channel slip ring with 3A twisted pair shielding delivers clean data with <140mV noise, <0.1Ω static resistance, <0.01Ω dynamic resistance, >250MΩ insulation, and 1×10⁷ revolution life.
◆ Wide-Range Thermal Chamber
600×600×500 mm chamber spans -55°C to +150°C with ±0.5°C fluctuation, ±2°C deviation, 2°C gradient, and 5°C/min change rate for efficient cycling.
◆ Stable Mechanical Foundation
Φ520 mm table maintains ±0.02 mm flatness and ±0.03 mm runout, providing a repeatable mounting surface for sensitive test articles.
◆ Applications
Inertial navigation, aerospace guidance, optoelectronic systems, and automotive sensor validation under combined environmental and motion stress.
◆ A Complete Test Solution
By unifying precision positioning, thermal conditioning, and signal integrity, this turntable eliminates cross-platform handling errors and accelerates development cycles.
